Description

Spherical pure glass beads.

Typical Properties

Appearance: Transparent spheres
Specific Gravity (g/cc): 2.5
Bulk Density (lb/ft³): 117
Hardness, MOH: 5-6
Compressive Strength (psi): 10,000 minimum
Typical Partical Diameter: Fine at 65 micron (230 mesh) and Coarse at 600 micron (30 mesh)

Advantages

• Not adversely affected by pressure, temperature, or mud chemistry.
• Can be used in any type of system.
• Superior strength and 75% roundness.
• Contains no free silica.

Application

• Horizontal Drilling—Improved sliding ability, extended lateral drilling capability.
• Deviated, crooked holes—Reduced torque and drag.
• Running casing, liner—Reduced drag created by closer tolerances and stiffer hook up.
